DOCUMENTS AND MAPS

Maps

These are maps for the proposed Wild Horse Reservoir Project. Click the maps below to view a larger image.

For more information on the alternatives that were evaluated, please visit the Identification of Project Alternatives blog post.

Proposed Wild Horse Reservoir Project with one dam, inlet and outlet pipelines, Otero Conveyance System, CR53 realignment to the east of the reservoir, and pipeline from Wild Horse Reservoir to Spinney Mountain Reservoir.

Proposed Wild Horse Reservoir Project Site Map

Map overview of Wild Horse Reservoir project alternatives: Wild Horse South Reservoir, Small Wild Horse Reservoir, and Spinney Mountain Reservoir Enlargement. Additional features include pipeline routes and road realignments for CR 53. More information can be found on the Project Alternatives webpage.

Wild Horse Reservoir Project Alternatives Map (These were the alternatives evaluated in preparation for the initial National Environmental Policy Act [NEPA] process)

Aurora Water Supply Map

Aurora Water’s Water Supply Map

CR 53 realignment wraps around the east side of the proposed Wild Horse Reservoir Project from existing CR53 to Dog Chief Trail near Caddo Rd., across Hopi Trail to Chickasaw Rd., down Chickasaw Rd. to Chimapavi Trail, and then merges with existing CR53 south of the project.

Proposed Wild Horse South Reservoir site with street names

Map of Denver Basin Aquifer Storage and Recovery Alternative. Twenty-one wells throughout the city of Aurora with pipelines connecting all the wells. A reverse osmosis plant would be just west of the city.

Denver Basin Aquifer Storage and Recovery (ASR) Map

Documents

Updated fact sheets will be available soon.
